Product process
1. Aluminum profile preparing (Raw profile coating or other treatment).
2. Mitered and cutting process.
3. Reinforcement steel cutting and fixing.
4. Aluminum window frame and sash frame assembling.
5. Glazing.
6. Final assembling and hardware assembling.
7. Cleaning, testing packing and loading. 1. 70mm frame depth for standard bi-fold system.
2. Lower sill 20mm is very popular in Australia
3. L sharp handle with key lock
4. Excellent ventilation control.
5. Provides superior weatherproofing.
6. Quality anti-scratch protective wrapping is optionable for all products.
7. Glazing bar between the double glazing or attaching the surface is optional.
8. Gracious and elegant, yet practical and durable
Materials:
1.Aluminium profile:Standard aluminium profile 1.4mm for windows and 2.0mm thickness for doors.
2.Profile surface treatment:
powder coated(with 70um thickness)
Anodized(with 15um thickness)
Electrophoresis(with 25um thickness)
PVDF(with 40um thickness)
3.Safety Glazing options:
A: single glazed like 5,6,8,10,12mm glass
B: double glazed like 5mm-9A-5mm
4.Glass option: Tempered glass, Low-e glass, tinted glass,frosted glass laminated glass and so on.
5.window seal:Rubber(EPDM) or silicone sealant.
6.Hardware: China Top brand
7.Measurement: Customized products according to clients
8.Performance: Corrosion-resistant, durable,non-deformable,energy-saving and ECO-friendly
